Non Magnetic 2 Axis Turntable 50kg Payload With Thermal Chamber

Name: Non Magnetic 2 Axis Turntable 50kg Payload With Thermal Chamber
Brand: Firepower
Price: 1 USD

Buy cheap Non Magnetic 2 Axis Turntable 50kg Payload With Thermal Chamber product

Brand Name : Firepower

Model Number : 2SM-320

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T, L/C

Supply Ability : 1000/month

Delivery Time : 10 days for sample

Packaging Details : carton with sponge

Product name : TURNTABLE WITH THERMAL CHAMBER

payload : 50kg

Table top diameter : 550 mm

Number of axis : Two

Angular freedom : ±360

Contact Now

2 axis non-magnetic turntable, dual axis magnetic free motion simulate turntable

Main functions:

Position control, speed control and swing control functions;

It has the functions of computer automatic state control, data acquisition, processing and display.

It can be used for local operation and remote control of the upper computer. Serial communication (RS232 or RS422) and parallel communication interface are used for remote control, which can transmit the working status of the turntable to the upper computer, including the position and rate information of the turntable. The communication frequency of serial communication data is not less than 50HZ, and that of parallel communication data is not less than 1KHZ.

The upper computer control software can run normally on WIN98, WINXP or WIN2000 platform.

Technical specifications of equipment

№	Name of the parameter	Value of the parameter
1	Maximum payload with the armature	50 kg.
2	Table top diameter	550 mm
3	Number of axis	Two
4	The height of the system from down to the table top	550mm
5	Load attachment points on the table top	By the needs of the customer
6	Orientation of axis	Vertical and horizontal
		Inner Axis	Outer Axis
7	Angular freedom	±360o	±360o
8	Accuracy	≤1arc sec RSS	≤2 arc sec RSS
9	Stability -over 360°	0.005%	0.005%
10	Angular speed resolution	0,001 deg/sec	0,001 deg/sec
11	Minimal acceleration	0,001 deg/sec2	0,001 deg/sec2
12	Maximal accleraion	600 deg/sec2	200 deg/sec2
13	Range	Not less than ±1000 deg/sec	Not less than ±350 deg/sec
14	Controller	With the built in computer With the external computer. Connect by RS-422 or Ethernet
15	Bandwidth (no load)	50 Hz at -3dB	20 Hz at -3dB
16	Power supply 50 Hz	230 ±10%	230 ± 10%
17	Slip rings :80 lines	1.Rings: 16 lines, 2А 2.Rings: 44 lines, 3А 2.Rings: 20 lines ,5А
	Main parameter of the temperature chamber:
18	Temperature Range:	-60—+100	°C
19	Heating Rate:	4	°C/min
20	Cooling Rate:	2	°C/min
21	Stability:	±1	°C
22	The inner volume of the temperature chamber (LхWхH)	560mm х 560mm х 630 mm
23	Corrosion resistance in the chamber for the long time usage with high humidity	Up to 98%
24	Cooling type	Freon condenser with air cooling
25	External dimensions with the temperature chamber, ± 10%,	2292mm, 1050mm, 2075mm

Product Tags:

non magnetic 2 Axis Turntable

2 Axis Turntable 50kg

Non Magnetic 2 Axis Turntable 50kg Payload With Thermal Chamber Images
